Set Up Self-Hosted Kafka Private Link Service in Azure

This document describes how to set up Private Link service for self-hosted Kafka in Azure, and how to make it work with TiDB Cloud.

The mechanism works as follows:

  1. The TiDB Cloud virtual network connects to the Kafka virtual network through private endpoints.
  2. Kafka clients need to communicate directly to all Kafka brokers.
  3. Each Kafka broker is mapped to a unique port of endpoints within the TiDB Cloud virtual network.
  4. Leverage the Kafka bootstrap mechanism and Azure resources to achieve the mapping.

The following diagram shows the mechanism.

Connect to Azure Self-Hosted Kafka Private Link Service

The document provides an example of connecting to a Kafka Private Link service in Azure. While other configurations are possible based on similar port-mapping principles, this document covers the fundamental setup process of the Kafka Private Link service. For production environments, a more resilient Kafka Private Link service with enhanced operational maintainability and observability is recommended.

Prerequisites

  1. Ensure that you have the following authorization to set up a Kafka Private Link service in your own Azure account.

    • Manage virtual machines
    • Manage virtual networks
    • Manage load balancers
    • Manage private link services
    • Connect to virtual machines to configure Kafka nodes

  2. Create a TiDB Cloud Dedicated cluster on Azure if you do not have one.

  3. Get the Kafka deployment information from your TiDB Cloud Dedicated cluster.

    1. In the TiDB Cloud console, navigate to the Clusters page, and then click the name of your target cluster to go to its overview page.
    2. In the left navigation pane, click Data > Changefeed.
    3. On the Changefeed page, click Create Changefeed in the upper-right corner, and then provide the following information:
      1. In Destination, select Kafka.
      2. In Connectivity Method, select Private Link.
    4. Note down the region information and the subscription of the TiDB Cloud Azure account in Reminders before proceeding. You will use it to authorize TiDB Cloud to access the Kafka Private Link service.
    5. Generate the Kafka Advertised Listener Pattern for your Kafka Private Link service by providing a unique random string.
      1. Input a unique random string. It can only include numbers or lowercase letters. You will use it to generate Kafka Advertised Listener Pattern later.
      2. Click Check usage and generate to check if the random string is unique and generate Kafka Advertised Listener Pattern that will be used to assemble the EXTERNAL advertised listener for Kafka brokers.

Note down all the deployment information. You need to use it to configure your Kafka Private Link service later.

The following table shows an example of the deployment information.

InformationValueNote
RegionVirginia (eastus)N/A
Subscription of TiDB Cloud Azure account99549169-6cee-4263-8491-924a3011ee31N/A
Kafka Advertised Listener PatternThe unique random string: abcGenerated pattern: <broker_id>.abc.eastus.azure.3199745.tidbcloud.com:<port>;

Step 1. Set up a Kafka cluster

If you need to deploy a new cluster, follow the instructions in Deploy a new Kafka cluster.

If you need to expose an existing cluster, follow the instructions in Reconfigure a running Kafka cluster.

Deploy a new Kafka cluster

1. Set up the Kafka virtual network

  1. Log in to the Azure portal, go to the Virtual networks page, and then click + Create to create a virtual network.

  2. In the Basic tab, select your Subscription, Resource group, and Region, enter a name (for example, kafka-pls-vnet) in the Virtual network name field, and then click Next.

  3. In the Security tab, enable Azure Bastion, and then click Next.

  4. In the IP addresses tab, do the following:

    1. Set the address space of your virtual network, for example, 10.0.0.0/16.

    2. Click Add a subnet to create a subnet for brokers, fill in the following information, and then click Add.

      • Name: brokers-subnet
      • IP address range: 10.0.0.0/24
      • Size: /24 (256 addresses)

      An AzureBastionSubnet will be created by default.

  5. Click Review + create to verify the information.

  6. Click Create.

2. Set up Kafka brokers

2.1. Create broker nodes

  1. Log in to the Azure portal, go to the Virtual machines page, click + Create, and then select Azure virtual machine.
  2. In the Basic tab, select your Subscription, Resource group, and Region, fill in the following information, and then click Next : Disks.
    • Virtual machine name: broker-node
    • Availability options: Availability zone
    • Zone options: Self-selected zone
    • Availability zone: Zone 1, Zone 2, Zone 3
    • Image: Ubuntu Server 24.04 LTS - x64 Gen2
    • VM architecture: x64
    • Size: Standard_D2s_v3
    • Authentication type: SSH public key
    • Username: azureuser
    • SSH public key source: Generate new key pair
    • Key pair name: kafka_broker_key
    • Public inbound ports: Allow selected ports
    • Select inbound ports: SSH (22)
  3. Click Next : Networking, and then fill in the following information in the Networking tab:
    • Virtual network: kafka-pls-vnet
    • Subnet: brokers-subnet
    • Public IP: None
    • NIC network security group: Basic
    • Public inbound ports: Allow selected ports
    • Select inbound ports: SSH (22)
    • Load balancing options: None
  4. Click Review + create to verify the information.
  5. Click Create. A Generate new key pair message is displayed.
  6. Click Download private key and create resource to download the private key to your local machine. You can see the progress of virtual machine creation.

2.2. Prepare Kafka runtime binaries

After the deployment of your virtual machine is completed, take the following steps:

  1. In the Azure portal, go to the Resource groups page, click your resource group name, and then navigate to the page of each broker node (broker-node-1, broker-node-2, and broker-node-3).

  2. On each page of the broker node, click Connect > Bastion in the left navigation pane, and then fill in the following information:

    • Authentication Type: SSH Private Key from Local File
    • Username: azureuser
    • Local File: select the private key file that you downloaded before
    • Select the Open in new browser tab option

  3. On each page of the broker node, click Connect to open a new browser tab with a Linux terminal. For the three broker nodes, you need to open three browser tabs with Linux terminals.

  4. In each Linux terminal, run the following commands to download binaries in each broker node.

    # Download Kafka and OpenJDK, and then extract the files. You can choose the binary version based on your preference.
wget https://archive.apache.org/dist/kafka/3.7.1/kafka_2.13-3.7.1.tgz
tar -zxf kafka_2.13-3.7.1.tgz
wget https://download.java.net/java/GA/jdk22.0.2/c9ecb94cd31b495da20a27d4581645e8/9/GPL/openjdk-22.0.2_linux-x64_bin.tar.gz
tar -zxf openjdk-22.0.2_linux-x64_bin.tar.gz

2.3. Set up Kafka nodes on each broker node

  1. Set up a KRaft Kafka cluster with three nodes. Each node serves both as a broker and a controller. For each broker node:

    1. Configure listeners. All three brokers are the same and act as brokers and controller roles.

      1. Configure the same CONTROLLER listener for all controller role nodes. If you only want to add the broker role nodes, you can omit the CONTROLLER listener in server.properties.
      2. Configure two broker listeners: INTERNAL for internal Kafka client access and EXTERNAL for access from TiDB Cloud.

    2. For advertised.listeners, do the following:

      1. Configure an INTERNAL advertised listener for each broker using the internal IP address of the broker node, which allows internal Kafka clients to connect to the broker via the advertised address.
      2. Configure an EXTERNAL advertised listener based on Kafka Advertised Listener Pattern you get from TiDB Cloud for each broker node to help TiDB Cloud distinguish between different brokers. Different EXTERNAL advertised listeners help Kafka clients from the TiDB Cloud side route requests to the right broker.
        • Use different <port> values to differentiate brokers in Kafka Private Link service access. Plan a port range for the EXTERNAL advertised listeners of all brokers. These ports do not have to be actual ports listened to by brokers. They are ports listened to by the load balancer in the Private Link service that will forward requests to different brokers.
        • It is recommended to configure different broker IDs for different brokers to make it easy for troubleshooting.

    3. The planning values:

      • CONTROLLER port: 29092
      • INTERNAL port: 9092
      • EXTERNAL port: 39092
      • Range of the EXTERNAL advertised listener ports: 9093~9095

  2. Use SSH to log in to each broker node. Create a configuration file ~/config/server.properties with the following content for each broker node respectively.

    # broker-node-1 ~/config/server.properties
# 1. Replace {broker-node-1-ip}, {broker-node-2-ip}, {broker-node-3-ip} with the actual IP addresses.
# 2. Configure EXTERNAL in "advertised.listeners" based on the "Kafka Advertised Listener Pattern" in the "Prerequisites" section.
# 2.1 The pattern is "<broker_id>.abc.eastus.azure.3199745.tidbcloud.com:<port>".
# 2.2 So the EXTERNAL can be "b1.abc.eastus.azure.3199745.tidbcloud.com:9093". Replace <broker_id> with "b" prefix plus "node.id" properties, and replace <port> with a unique port (9093) in the port range of the EXTERNAL advertised listener.
process.roles=broker,controller
node.id=1
controller.quorum.voters=1@{broker-node-1-ip}:29092,2@{broker-node-2-ip}:29092,3@{broker-node-3-ip}:29092
listeners=INTERNAL://0.0.0.0:9092,CONTROLLER://0.0.0.0:29092,EXTERNAL://0.0.0.0:39092
inter.broker.listener.name=INTERNAL
advertised.listeners=INTERNAL://{broker-node-1-ip}:9092,EXTERNAL://b1.abc.eastus.azure.3199745.tidbcloud.com:9093
controller.listener.names=CONTROLLER
listener.security.protocol.map=INTERNAL:PLAINTEXT,CONTROLLER:PLAINTEXT,EXTERNAL:PLAINTEXT,SSL:SSL,SASL_PLAINTEXT:SASL_PLAINTEXT,SASL_SSL:SASL_SSL
log.dirs=./data

    # broker-node-2 ~/config/server.properties
# 1. Replace {broker-node-1-ip}, {broker-node-2-ip}, {broker-node-3-ip} with the actual IP addresses.
# 2. Configure EXTERNAL in "advertised.listeners" based on the "Kafka Advertised Listener Pattern" in the "Prerequisites" section.
# 2.1 The pattern is "<broker_id>.abc.eastus.azure.3199745.tidbcloud.com:<port>".
# 2.2 So the EXTERNAL can be "b2.abc.eastus.azure.3199745.tidbcloud.com:9094". Replace <broker_id> with "b" prefix plus "node.id" properties, and replace <port> with a unique port (9094) in the port range of the EXTERNAL advertised listener.
process.roles=broker,controller
node.id=2
controller.quorum.voters=1@{broker-node-1-ip}:29092,2@{broker-node-2-ip}:29092,3@{broker-node-3-ip}:29092
listeners=INTERNAL://0.0.0.0:9092,CONTROLLER://0.0.0.0:29092,EXTERNAL://0.0.0.0:39092
inter.broker.listener.name=INTERNAL
advertised.listeners=INTERNAL://{broker-node-2-ip}:9092,EXTERNAL://b2.abc.eastus.azure.3199745.tidbcloud.com:9094
controller.listener.names=CONTROLLER
listener.security.protocol.map=INTERNAL:PLAINTEXT,CONTROLLER:PLAINTEXT,EXTERNAL:PLAINTEXT,SSL:SSL,SASL_PLAINTEXT:SASL_PLAINTEXT,SASL_SSL:SASL_SSL
log.dirs=./data

    # broker-node-3 ~/config/server.properties
# 1. Replace {broker-node-1-ip}, {broker-node-2-ip}, {broker-node-3-ip} with the actual IP addresses.
# 2. Configure EXTERNAL in "advertised.listeners" based on the "Kafka Advertised Listener Pattern" in the "Prerequisites" section.
# 2.1 The pattern is "<broker_id>.abc.eastus.azure.3199745.tidbcloud.com:<port>".
# 2.2 So the EXTERNAL can be "b3.abc.eastus.azure.3199745.tidbcloud.com:9095". Replace <broker_id> with "b" prefix plus "node.id" properties, and replace <port> with a unique port (9095) in the port range of the EXTERNAL advertised listener.
process.roles=broker,controller
node.id=3
controller.quorum.voters=1@{broker-node-1-ip}:29092,2@{broker-node-2-ip}:29092,3@{broker-node-3-ip}:29092
listeners=INTERNAL://0.0.0.0:9092,CONTROLLER://0.0.0.0:29092,EXTERNAL://0.0.0.0:39092
inter.broker.listener.name=INTERNAL
advertised.listeners=INTERNAL://{broker-node-3-ip}:9092,EXTERNAL://b3.abc.eastus.azure.3199745.tidbcloud.com:9095
controller.listener.names=CONTROLLER
listener.security.protocol.map=INTERNAL:PLAINTEXT,CONTROLLER:PLAINTEXT,EXTERNAL:PLAINTEXT,SSL:SSL,SASL_PLAINTEXT:SASL_PLAINTEXT,SASL_SSL:SASL_SSL
log.dirs=./data

  3. Create a script, and then execute it to start the Kafka broker in each broker node.

    SCRIPT_DIR="$(cd "$(dirname "${BASH_SOURCE[0]}")" && pwd)"
export JAVA_HOME="$SCRIPT_DIR/jdk-22.0.2"
KAFKA_DIR="$SCRIPT_DIR/kafka_2.13-3.7.1/bin"
KAFKA_STORAGE_CMD=$KAFKA_DIR/kafka-storage.sh
KAFKA_START_CMD=$KAFKA_DIR/kafka-server-start.sh
KAFKA_DATA_DIR=$SCRIPT_DIR/data
KAFKA_LOG_DIR=$SCRIPT_DIR/log
KAFKA_CONFIG_DIR=$SCRIPT_DIR/config

KAFKA_PIDS=$(ps aux | grep 'kafka.Kafka' | grep -v grep | awk '{print $2}')
if [ -z "$KAFKA_PIDS" ]; then
echo "No Kafka processes are running."
else
echo "Killing Kafka processes with PIDs: $KAFKA_PIDS"
for PID in $KAFKA_PIDS; do
    kill -9 $PID
    echo "Killed Kafka process with PID: $PID"
done
echo "All Kafka processes have been killed."
fi

rm -rf $KAFKA_DATA_DIR
mkdir -p $KAFKA_DATA_DIR
rm -rf $KAFKA_LOG_DIR
mkdir -p $KAFKA_LOG_DIR

$KAFKA_STORAGE_CMD format -t "BRl69zcmTFmiPaoaANybiw" -c "$KAFKA_CONFIG_DIR/server.properties" > $KAFKA_LOG_DIR/server_format.log
LOG_DIR=$KAFKA_LOG_DIR nohup $KAFKA_START_CMD "$KAFKA_CONFIG_DIR/server.properties" &

2.4. Test the cluster setting

  1. Test the Kafka bootstrap.

    export JAVA_HOME=/home/azureuser/jdk-22.0.2

# Bootstrap from INTERNAL listener
./kafka_2.13-3.7.1/bin/kafka-broker-api-versions.sh --bootstrap-server {one_of_broker_ip}:9092 | grep 9092
# Expected output (the actual order might be different)
{broker-node-1-ip}:9092 (id: 1 rack: null) -> (
{broker-node-2-ip}:9092 (id: 2 rack: null) -> (
{broker-node-3-ip}:9092 (id: 3 rack: null) -> (

# Bootstrap from EXTERNAL listener
./kafka_2.13-3.7.1/bin/kafka-broker-api-versions.sh --bootstrap-server {one_of_broker_ip}:39092
# Expected output for the last 3 lines (the actual order might be different)
# The difference in the output from "bootstrap from INTERNAL listener" is that exceptions or errors might occur because advertised listeners cannot be resolved in kafka-pls-vnet.
# TiDB Cloud will make these addresses resolvable and route requests to the correct broker when you create a changefeed connected to this Kafka cluster via Private Link Service.
b1.abc.eastus.azure.3199745.tidbcloud.com:9093 (id: 1 rack: null) -> ERROR: org.apache.kafka.common.errors.DisconnectException
b2.abc.eastus.azure.3199745.tidbcloud.com:9094 (id: 2 rack: null) -> ERROR: org.apache.kafka.common.errors.DisconnectException
b3.abc.eastus.azure.3199745.tidbcloud.com:9095 (id: 3 rack: null) -> ERROR: org.apache.kafka.common.errors.DisconnectException

  2. Create a producer script produce.sh in the bastion node.

    BROKER_LIST=$1

SCRIPT_DIR="$(cd "$(dirname "${BASH_SOURCE[0]}")" && pwd)"
export JAVA_HOME="$SCRIPT_DIR/jdk-22.0.2"
KAFKA_DIR="$SCRIPT_DIR/kafka_2.13-3.7.1/bin"
TOPIC="test-topic"

create_topic() {
    echo "Creating topic if it does not exist..."
    $KAFKA_DIR/kafka-topics.sh --create --topic $TOPIC --bootstrap-server $BROKER_LIST --if-not-exists --partitions 3 --replication-factor 3
}

produce_messages() {
    echo "Producing messages to the topic..."
    for ((chrono=1; chrono <= 10; chrono++)); do
        message="Test message "$chrono
        echo "Create "$message
        echo $message | $KAFKA_DIR/kafka-console-producer.sh --broker-list $BROKER_LIST --topic $TOPIC
    done
}
create_topic
produce_messages

  3. Create a consumer script consume.sh in the bastion node.

    BROKER_LIST=$1
SCRIPT_DIR="$(cd "$(dirname "${BASH_SOURCE[0]}")" && pwd)"
export JAVA_HOME="$SCRIPT_DIR/jdk-22.0.2"
KAFKA_DIR="$SCRIPT_DIR/kafka_2.13-3.7.1/bin"
TOPIC="test-topic"
CONSUMER_GROUP="test-group"
consume_messages() {
    echo "Consuming messages from the topic..."
    $KAFKA_DIR/kafka-console-consumer.sh --bootstrap-server $BROKER_LIST --topic $TOPIC --from-beginning --timeout-ms 5000 --consumer-property group.id=$CONSUMER_GROUP
}
consume_messages

  4. Run the produce.sh and consume.sh scripts. These scripts automatically test connectivity and message flow to verify that the Kafka cluster is functioning correctly. The produce.sh script creates a topic with --partitions 3 --replication-factor 3, sends test messages, and connects to all three brokers using the --broker-list parameter. The consume.sh script reads messages from the topic to confirm successful message delivery.

    # Test write message.
./produce.sh {one_of_broker_ip}:9092

    # Expected output
Creating topic if it does not exist...

Producing messages to the topic...
Create Test message 1
>>Create Test message 2
>>Create Test message 3
>>Create Test message 4
>>Create Test message 5
>>Create Test message 6
>>Create Test message 7
>>Create Test message 8
>>Create Test message 9
>>Create Test message 10

    # Test read message
./consume.sh {one_of_broker_ip}:9092

    # Expected example output (the actual message order might be different)
Consuming messages from the topic...
Test message 3
Test message 4
Test message 5
Test message 9
Test message 10
Test message 6
Test message 8
Test message 1
Test message 2
Test message 7
[2024-11-01 08:54:27,547] ERROR Error processing message, terminating consumer process:  (kafka.tools.ConsoleConsumer$)
org.apache.kafka.common.errors.TimeoutException
Processed a total of 10 messages

Reconfigure a running Kafka cluster

Ensure that your Kafka cluster is deployed in the same region as the TiDB cluster.

1. Configure the EXTERNAL listener for brokers

The following configuration applies to a Kafka KRaft cluster. The ZK mode configuration is similar.

  1. Plan configuration changes.

    1. Configure an EXTERNAL listener for every broker for external access from TiDB Cloud. Select a unique port as the EXTERNAL port, for example, 39092.
    2. Configure an EXTERNAL advertised listener based on Kafka Advertised Listener Pattern you get from TiDB Cloud for every broker node to help TiDB Cloud differentiate between different brokers. Different EXTERNAL advertised listeners help Kafka clients from TiDB Cloud side route requests to the right broker.
      • <port> differentiates brokers from Kafka Private Link service access points. Plan a port range for EXTERNAL advertised listeners of all brokers, for example, range from 9093. These ports do not have to be actual ports listened to by brokers. They are ports listened to by the load balancer for Private Link service that will forward requests to different brokers.
      • It is recommended to configure different broker IDs for different brokers to make it easy for troubleshooting.

  2. Use SSH to log in to each broker node. Modify the configuration file of each broker with the following content:

    # Add EXTERNAL listener
listeners=INTERNAL:...,EXTERNAL://0.0.0.0:39092

# Add EXTERNAL advertised listeners based on the "Kafka Advertised Listener Pattern" in the "Prerequisites" section
# 1. The pattern is "<broker_id>.abc.eastus.azure.3199745.tidbcloud.com:<port>".
# 2. So the EXTERNAL can be "bx.abc.eastus.azure.3199745.tidbcloud.com:xxxx". Replace <broker_id> with "b" prefix plus "node.id" properties, and replace <port> with a unique port in the port range of the EXTERNAL advertised listener.
# For example
advertised.listeners=...,EXTERNAL://b1.abc.eastus.azure.3199745.tidbcloud.com:9093

# Configure the EXTERNAL map
listener.security.protocol.map=...,EXTERNAL:PLAINTEXT

  3. After you reconfigure all the brokers, restart your Kafka brokers one by one.

2. Test EXTERNAL listener settings in your internal network

You can download Kafka and OpenJDK in your Kafka client node.

# Download Kafka and OpenJDK, and then extract the files. You can choose the binary version based on your preference.
wget https://archive.apache.org/dist/kafka/3.7.1/kafka_2.13-3.7.1.tgz
tar -zxf kafka_2.13-3.7.1.tgz
wget https://download.java.net/java/GA/jdk22.0.2/c9ecb94cd31b495da20a27d4581645e8/9/GPL/openjdk-22.0.2_linux-x64_bin.tar.gz
tar -zxf openjdk-22.0.2_linux-x64_bin.tar.gz

Execute the following script to test if the bootstrap works as expected.

export JAVA_HOME=~/jdk-22.0.2

# Bootstrap from the EXTERNAL listener
./kafka_2.13-3.7.1/bin/kafka-broker-api-versions.sh --bootstrap-server {one_of_broker_ip}:39092

# Expected output for the last 3 lines (the actual order might be different)
# There will be some exceptions or errors because advertised listeners cannot be resolved in your Kafka network.
# TiDB Cloud will make these addresses resolvable and route requests to the correct broker when you create a changefeed connected to this Kafka cluster via Private Link Service.
b1.abc.eastus.azure.3199745.tidbcloud.com:9093 (id: 1 rack: null) -> ERROR: org.apache.kafka.common.errors.DisconnectException
b2.abc.eastus.azure.3199745.tidbcloud.com:9094 (id: 2 rack: null) -> ERROR: org.apache.kafka.common.errors.DisconnectException
b3.abc.eastus.azure.3199745.tidbcloud.com:9095 (id: 3 rack: null) -> ERROR: org.apache.kafka.common.errors.DisconnectException

1. Set up the load balancer

  1. Log in to the Azure portal, go to the Load balancing page, and then click + Create to create a load balancer.

  2. In the Basic tab, select your Subscription, Resource group, and Region, fill in the following instance information, and then click Next : Frontend IP configuration >.

    • Name: kafka-lb
    • SKU: Standard
    • Type: Internal
    • Tier: Regional

  3. In the Frontend IP configuration tab, click + Add a frontend IP configuration, fill in the following information, click Save, and then click Next : Backend pools >.

    • Name: kafka-lb-ip
    • IP version: IPv4
    • Virtual network: kafka-pls-vnet
    • Subnet: brokers-subnet
    • Assignment: Dynamic
    • Availability zone: Zone-redundant

  4. In the Backend pools tab, add three backend pools as follows, and then click Next : Inbound rules.

    • Name: pool1; Backend Pool Configuration: NIC; IP configurations: broker-node-1
    • Name: pool2; Backend Pool Configuration: NIC; IP configurations: broker-node-2
    • Name: pool3; Backend Pool Configuration: NIC; IP configurations: broker-node-3

  5. In the Inbound rules tab, add three load balancing rules as follows:

    1. Rule 1

      • Name: rule1
      • IP version: IPv4
      • Frontend IP address: kafka-lb-ip
      • Backend pool: pool1
      • Protocol: TCP
      • Port: 9093
      • Backend port: 39092
      • Health probe: click Create New and fill in the probe information.
        • Name: kafka-lb-hp
        • Protocol: TCP
        • Port: 39092

    2. Rule 2

      • Name: rule2
      • IP version: IPv4
      • Frontend IP address: kafka-lb-ip
      • Backend pool: pool2
      • Protocol: TCP
      • Port: 9094
      • Backend port: 39092
      • Health probe: click Create New and fill in the probe information.
        • Name: kafka-lb-hp
        • Protocol: TCP
        • Port: 39092

    3. Rule 3

      • Name: rule3
      • IP version: IPv4
      • Frontend IP address: kafka-lb-ip
      • Backend pool: pool3
      • Protocol: TCP
      • Port: 9095
      • Backend port: 39092
      • Health probe: click Create New and fill in the probe information.
        • Name: kafka-lb-hp
        • Protocol: TCP
        • Port: 39092

  6. Click Next : Outbound rule, click Next : Tags >, and then click Next : Review + create to verify the information.

  7. Click Create.

  1. Log in to the Azure portal, go to the Private link services page, and then click + Create to create a Private Link service for the Kafka load balancer.

  2. In the Basic tab, select your Subscription, Resource group, and Region, fill in kafka-pls in the Name field, and then click Next : Outbound settings >.

  3. In the Outbound settings tab, fill in the parameters as follows, and then click Next : Access security >.

    • Load balancer: kafka-lb
    • Load balancer frontend IP address: kafka-lb-ip
    • Source NAT subnet: kafka-pls-vnet/brokers-subnet

  4. In the Access security tab, do the following:

    • For Visibility, select Restricted by subscription or Anyone with your alias.
    • For Subscription-level access and auto-approval, click Add subscriptions to add the subscription of TiDB Cloud Azure account you got in Prerequisites.

  5. Click Next : Tags >, and then click Next : Review + create > to verify the information.

  6. Click Create. When the operation is done, note down the alias of the Private Link service for later use.

Step 3. Connect from TiDB Cloud

  1. Return to the TiDB Cloud console to create a changefeed for the cluster to connect to the Kafka cluster by Private Link. For more information, see Sink to Apache Kafka.

  2. When you proceed to Configure the changefeed target > Connectivity Method > Private Link, fill in the following fields with corresponding values and other fields as needed.

    • Kafka Advertised Listener Pattern: the unique random string that you use to generate Kafka Advertised Listener Pattern in Prerequisites.
    • Alias of the Private Link Service: the alias of the Private Link service that you got in 2. Set up Private Link Service.
    • Bootstrap Ports: 9093,9094,9095.

  3. Proceed with the steps in Sink to Apache Kafka.

Now you have successfully finished the task.

FAQ

If you have already followed this document to successfully set up the connection from the first project, you can connect to the same Kafka Private Link service from the second project as follows:

  1. Follow instructions from the beginning of this document.

  2. When you proceed to Step 1. Set up a Kafka cluster, follow Reconfigure a running Kafka cluster to create another group of EXTERNAL listeners and advertised listeners. You can name it as EXTERNAL2. Note that the port range of EXTERNAL2 can overlap with the EXTERNAL.

  3. After reconfiguring brokers, create a new load balancer and a new Private Link service.

  4. Configure the TiDB Cloud connection with the following information:

    • New Kafka Advertised Listener Group
    • New Private Link service

Was this page helpful?

Request docs changesAsk the community
